ShanDong Meidi Medical Equipment Co.,Ltd
| Lead | Standard 12 leads |
| Acquisition | Simultaneous 12leads |
| A/D Converter | 14bit |
| Sampling Rate | 1000Hz |
| Working Mode | Manual/Auto |
| Interference Filter | AC Filter and EMG Filter |
| CMMR | ≥100dB (with AC filter) |
| Input Circuit | Floating, protection circuit against Defibrillator effect |
| Input Circuit Current | ≤0.1μA |
| Input Impedance | ≥50MΩ |
| Patient Current Leakage | ＜10μA |
| Calibrating Voltage | 1mV±2％ |
| Skin Voltage Tolerance | ≥±500mV |
| Time Constant | ≥3.2s |
| Frequency Response | 0.05 Hz～250Hz |
| Noise Level | ＜15μVp-p |
| Sensitivity Threshold | ≤20μV |
| Signal Channel Interference | ≤0.5mm |
| Printer | Thermal printer |
| Paper | 112mmx20m, roll |
| Page Speed | 6.25, 12.5, 25, 50mm/s (±3％) |
| Sensitivity Printer | 10mm/mV (AUTO), 2.5, 5, 10, 20mm/mV |
| CPU | 32 bits |
| Safe Class | GB9706.1, Class I, Type CF |
| Power Supply | AC 220V (±10%), 50Hz±1Hz, Power ≤60VA AC 85～265V, 50/60Hz DC14.8V (2200mAh), rechargeable Li-ion battery |
| Dimension | 310mm×270mm×73mm |
| Weight | 1.75kg (with battery) |
