| Features | 7 "display,touch screen Support Ecg analysis capabilities |
| Lead | standard 12 leads |
| lead acquisition | synchronously 12 leads |
| Input circuit | Floating; Protection circuit against Defibrillator effect |
| Input Impedance | ≥50MΩ |
| Input circuit current | ≤0.0.05μA |
| Record mode | Automatic: 3CH×4+1R, 3CH×4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2; Manual: 3CH, 2CH, 3CH+1R, 2CH+1R; Rhythm: Any lead selectable. |
| Filter | EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz DFT Filter: 0.05 Hz/ 0.15 Hz AC Filter: 50 Hz / 60Hz |
| CMRR | >100dB |
| Patient current leakage | <10μA |
| Input Circuit Current | <0.05µA |
| Frequency Response | 0.05Hz~150Hz (-3dB) |
| Sensitivity | 2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV |
| Anti-baseline Drift | Automatic |
| Time constant | ≥3.2s |
| Noise level | <15μVp-p |
| Paper speed | 12.5 mm/s, 25 mm/s, 50 mm/s |
| Recording mode | Thermal printing system |
| Paper specification | 80mmx20m paper roll |
